Hitec DB961WP Ultra Torque Waterproof Brushless High Voltage Servo. This ultra torque offering from Hitec uses huge brushless power to give it an impressive 55.0kg-cm (763.81oz-in) at 7.4V! All Hitec D-Series servos have been designed Hitec's cutting edge, custom engineering. Combining industry leading high-resolution, state-of-the-art ultra-response technology with a 32-bit MCU and 12-bit ADC for unprecedented programmability and flexibility, these servos deliver significantly smoother movement.
NOTE: Programmable features require the use of the Hitec servo programmer sold separately (HRC44427 or HRC44429).
Features:
- Full metal case
- IP67 Waterproof rating
- Robust gear train with dual ball bearings
- High performance brushless motor
- Programmable high response digital amplifier with MOSFET driver
Specifications:
- Operating Voltage: 6.0-7.4V
- Speed:
- @6.0V: 0.18sec/60°
- @7.4V: 0.15sec/60°
- Torque:
- @6.0V: 55.0kg-cm (763.81oz-in)
- @7.4V: 55.0kg-cm (763.81oz-in)
- Weight: 90.0g (3.17oz)
- Dimensions: 40x20x39mm (1.57x0.78x1.53in)
- Spline: 25T
- Motor Type: Brushless
- Water Resistance: IP67
Limited Warranty:
Hitec Servo Warranty: Each Hitec servo is backed by a limited two-year warranty from the date of purchase. Hitec RCD USA, INC. shall REPAIR OR REPLACE, at Hitec RCD, INC., defective equipment covered by this warranty, otherwise the purchaser and/or consumer is responsible for any charges for the repair or replacement of the product.
