The Spektrum™ S100 Smart USB-C Charger provides fast, easy charging for all modelers, especially using Smart batteries — with Auto Charge simplicity, one-connection balancing, IC3® or IC5® output ports for adapter-free convenience, and more.
- Capable of delivering up to 100W of charging power with compatible power supply and USB-C Cable
- Charges AND balances Smart G2 batteries with one simple IC3® or IC5® connection — no separate balance lead needed
- Auto Charge recognizes Smart battery charging parameters and begins safe, accurate charging automatically when connected
- Includes IC3® and IC5® charging output ports — no separate adapters required to charge different Spektrum™ Smart batteries
- Can also be used to charge many standard hobby 1S-4S LiPo, LiIon, LiHV, LiFe, and 1C - 12C Smart NiMH batteries. Note: The S100 will not charge non-Smart NiMH brand batteries.
- Accepts firmware updates via USB-C port
- Color LED screen and three button interface makes charging and checking on a battery's status simple
In The Box
- (1) S100 1x100W USB-C Smart Charger
- (1) 60W USB-C Cable to USB-C Cable
- (1) Product Instruction Manual
Needed to Complete
- (1) 10W minimum USB-C power supply adapter
*A higher wattage power supply will increase the output power of the S100 charger (up to 100W).
Product Specifications
- Display: LED
- Input Voltage: DC 5.0 - 20.0V, USB-C
- Product Height: 1.42" (36 mm)
- Programmable: Yes
- Over Current Protection: Yes
- Application: RC Model Battery Charger
- Peak Detection: Yes
- Short Circuit Protection: Yes
- Connector Type: IC3, IC5
- Maximum Charge Rate: 1A / 2A / 3A / 6A User Selectable
- Product Length: 3.86" (98 mm)
- Thermal Protection: Yes
- Battery Type: LiFe (3.3V per cell), LiHV (3.8V per cell), LiPo (3.7V per cell), Smart NiMH (1.2V per cell)
- PC Connectivity: Yes
- Battery Balance Connector: JST-XH
- Battery Temperature Monitoring: Yes
- Selectable Charge Rate: Yes
- Integrated Balancing: Yes - Internal Balancer & External Adapter
- Low Input Voltage Protection: Yes
- Product Width: 2.83" (72 mm)
- Software Updates: Yes
- Technology : Smart
