Receiver Overview:
FlySky FGr4P 2.4GHz 4-Channel AFHDS3 Receiver. The FGr4P is a four-channel, two-way receiver utilizing the AFHDS3 (Third Generation Automatic Frequency Hopping Digital System) protocol. Featuring dual antennas, a PPX6 nano waterproof rating, and a compact, lightweight design, this receiver supports four Newport function interfaces. These interfaces can be customized for various signal types, including i-BUS2, S.BUS, i-BUS, and PPM. Additionally, the FGr4D can function as a PWM converter, making it ideal for use in model cars or boats.
Features:
- Seamless integration with compatible FlySky AFHDS3 Transmitters
- Lightweight and compact, making it suitable for a wide range of applications
- Easy-to-use bind button for quick and straightforward binding
- Operates efficiently within a wide voltage range, making it versatile for different power supply setups
- Fail-safe settings enhance safety by ensuring the model behaves predictably in case of signal loss
- Utilizes the AFHDS3 protocol
Specifications:
- Input Voltage: 3.5-8.4V
- Frequency: 2.4GHz
- Channels: 4Ch
- Protocol: AFHDS3
- Antenna: Dual
- Dimensions: 1.1x0.8x0.6in (29x22x16.2mm)
- Weight: 0.28oz (8g)
Includes:
- (1) FlySky FGr4P 4-Channel Receiver
